We have a range of 3 tonne lift capacity loaders on offer from the standard 300 series to the 938 series we can meet your requirements
Specifications
| Item | Parameter | Unit |
| Rated load | 3.0 | t |
| Bucket capacity | 1.8 | m3 |
| Dumping height | 2930 | mm |
| Dumping distance | 1000 | mm |
| Dimension (L×W×H) | 7250 x 2580 x 3290 | mm |
| Operating weight | 10.6 | t |
| Boom lifting time | 5.68 | s |
| Total time of three devices | 10.3 | s |
| Wheelbase | 2900 | mm |
| Min. turning radius (bucket outer) | 6067 | mm |
| Rated power | 92 | kW |
| Long boom parameter | ||
| Bucket capacity | 1.5/1.8 | m3 |
| Rated load | 2.7/2.7 | t |
| Dimension (Length × Width × Height ) | 7540 x 2580 x 3290
7640 x 2580 x 3290 |
mm |
| Dumping height | 3290/3225 | mm |
| Dumping distance | 1092/1172 | mm |
| Operating weight | 10.6/10.8 | t |
| Attachment parameter－grasping grass | ||
| Dumping height | 3043 | mm |
| Dumping distance | 2036 | mm |
| Clamp body width | 2200 | mm |
| Max. opening | 2800 | mm |
| Attachment parameter－clamp（III） | ||
| Dumping height | 2784 | mm |
| Dumping distance | 1134 | mm |
| Min. circle diameter | 590 | mm |
| Max. opening | 1700 | mm |
| Attachment parameter－side dumping | ||
| Bucket width | 2650 | mm |
| Dimension | 7414 x 2650 x 3290 | mm |
| Dumping height (straight/side) dumping | 2813/3623 | mm |
| Dumping distance (straight/side) dumping | 1104/183 | mm |
| Lifting height (straight/side) dumping | 5120/6052 | mm |
| Attachment parameter－Sliding fork | ||
| Fork folding angle | 20 | ° |
| Attachment length | 1575 | mm |
| Attachment width | 1980 | mm |
| Attachment height | 1200 | mm |
| Fork teeth length | 1050 | mm |
When it comes to XCMG machinery, the LN 938 or the XCMG XC 938 is a machine especially suitable for loading and unloading prime movers. It is ideal in the feedlot application cleaning pens and mixing feed out of your feed bunkers. since its inception gold bug has modified the machines with the factory in order to meet the harsh Australian environment..
The new one piece type cab offers all round visibility, an adjustable instrument panel and overall comfortable operation.
Sufficient power is ensured through the powerful Cummins Engine, which delivers efficient and reliable power to the 3 tonne series machines.
